30kW Water-Cooled IP67 Integrated Water Pump Module with PMSM for Sweepers

  • 1
  • 2
  • 3

Contact Now

30kW Integrated Water Pump Module for Sweepers
PMSM, Water-Cooled, IP67 Protection
Modular Integrated Electric Pump Specifications
Pump Type Centrifugal Electric Pump Flow Rate 50 m³/h
Head 110 m Motor Type Permanent Magnet Synchronous Motor (PMSM)
Winding Configuration Star Connection Cooling Method Water Cooling (via flow channel)
Rated Voltage 380 VAC Battery Voltage 540 VDC
Rated Speed 3200 rpm Motor Protection Class IP67
Rated Power 30 kW Duty Cycle S1 (Continuous)
Rated Current 51 A Insulation Class Class H
30kW Water-Cooled IP67 Integrated Water Pump Module with PMSM for Sweepers
The Modular Integrated Electric Pump is a high-performance, space-saving solution that combines a 30kW permanent magnet synchronous motor (PMSM) with a centrifugal pump in a single, compact unit. Designed for demanding sanitation vehicle applications, this integrated module eliminates the need for external couplings and alignment, reducing installation complexity and improving overall system reliability.
With a flow rate of 50 m³/h and a head of 110 meters, this pump delivers powerful performance for high-pressure washing, dust suppression, and water transfer tasks on sweepers, street flushers, and other municipal vehicles. The water cooling system ensures optimal thermal management during continuous operation, while the IP67-rated motor provides complete protection against dust and water ingress for all-weather reliability.

30kW Water-Cooled IP67 Integrated Water Pump Module with PMSM for Sweepers

Key Features
  • Integrated Design - Motor and pump in one compact housing
  • 30kW PMSM Technology - High efficiency, precise speed control, low maintenance
  • Water Cooling - Superior thermal management for continuous duty applications
  • IP67 Protection - Dust-tight and waterproof for harsh outdoor environments
  • S1 Continuous Duty - Designed for extended operating hours
  • Class H Insulation - Withstands high temperatures for long-term durability
  • Modular Architecture - Easy integration into vehicle systems
This pump module is available for OEM/ODM customization, allowing voltage, interface, and performance adjustments to meet your specific vehicle or system requirements.

Product Tags:

30kW Integrated Water Pump Module



Water-Cooled Electric Drive Module



IP67 PMSM Pump Module
